TP-Link DR3650v-4G Omada 4G+ AX3000 VPN Router with VoIP

The TP-Link DR3650v-4G is a versatile, high-performance router designed for small to medium-sized businesses that require reliable internet connectivity, secure remote access, and integrated voice communication. Combining 4G+ LTE, Wi-Fi 6 (AX3000), and VoIP capabilities, this device offers a comprehensive networking solution.

Key Features

4G+ LTE Connectivity

• Dual Nano SIM Slots: Supports 4G+ Cat6 LTE with download speeds up to 300 Mbps and upload speeds up to 50 Mbps.

• USB 3.0 Port: Allows connection of 4G/3G USB modems for additional or backup internet connectivity.


Wi-Fi 6 (AX3000) Dual-Band Performance

• 5 GHz Band: Up to 2402 Mbps

• 2.4 GHz Band: Up to 574 Mbps

• Technologies: HE160, OFDMA, and 1024 QAM for improved speed, efficiency, and capacity.


VoIP Support

• 3× RJ11 Ports: Includes 2× FXS ports for connecting analog phones and 1× DSL port for broadband connectivity.

• Voice Codecs: Supports G.711 A/U law, G.726, G.729 A/B, and G.722 for high-quality voice communication.


VPN Support

• Multiple Protocols: Supports IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, and SSL VPN for secure remote access and site-to-site connectivity.

• High Capacity: Can handle up to 100 IPSec VPN tunnels, 50 PPTP/L2TP tunnels, and 55 OpenVPN tunnels simultaneously.


Centralized Cloud Management

• Omada SDN Integration: Seamlessly integrates into the Omada SDN platform, allowing for centralized cloud management via the web or Omada app.

• Zero-Touch Provisioning (ZTP): Simplifies deployment by allowing automatic configuration without manual intervention.


High Performance

• Processor: Dual-core ARM Cortex-A53

• Memory: 512MB DDR4 RAM

• Concurrent Sessions: Supports up to 150,000 concurrent sessions.

• NAT Throughput: Up to 945.8 Mbps.


Versatile Connectivity

• 5× Gigabit Ports: Includes 1× WAN/LAN port and 4× LAN ports for wired connections.

• 3× RJ11 Ports: 2× FXS ports for VoIP and 1× DSL port for broadband connectivity.

• USB 3.0 Port: Supports USB LTE dongles and storage devices.


Antennas

• Wi-Fi: 3× 5GHz 5dBi and 2.4GHz 3.5dBi dual-band detachable antennas.

• LTE: 2× 4.0dBi omnidirectional detachable antennas.


Dimensions and Power

• Dimensions: 226 × 131 × 35 mm

• Power Supply: 12V DC / 3.3A

• Max Power Consumption: 31.42W (with USB 3.0 connected).


Benefits

1. Reliable 4G+ LTE Connectivity: Ensures fast and stable internet access, even in areas with limited broadband infrastructure.

2. High-Speed Wi-Fi 6: Provides fast and efficient wireless connectivity for a wide range of devices.

3. Integrated VoIP Support: Enables cost-effective voice communication without the need for separate phone lines.

4. Secure Remote Access: Multiple VPN protocols ensure secure connections for remote users and branch offices.

5. Centralized Management: Omada SDN integration allows for easy monitoring and management of the network from a single interface.


Conclusion

The TP-Link DR3650v-4G Omada 4G+ AX3000 VPN Router with VoIP is an ideal choice for businesses seeking a comprehensive networking solution that combines high-speed internet connectivity, secure remote access, and integrated voice communication. Its advanced features and centralized management capabilities make it a valuable asset for modern business environments.

TP-Link DR3650v-4G Omada 4G AX3000 VPN Router w/VOIP

AX3000 Wi-Fi 6 with 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz*1*4 VDSL2 35b: Supports 350Mbps DSL Access*2 VDSL2/ADSL2+/ADSL2/ADSL Compatibility 4G+ Cat6 up to 300Mbps 2 x Embeded SlM Card Slots Centralised Cloud Management IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN Load Balancing Between DSL and Ethernet WAN Omada Mesh Technology*3 3 × RJ11 Ports (2 × FXS, 1 × DSL) & 5 × RJ45 Gigabit Ports & 1 × USB 3.0 Port Desktop/Wall Mounting 8.9 × 5.2 × 1.4 in (226 × 131.2 × 35 mm)

Specifications
